CEMB - ER90 EVO
Type of Product: Balancer   |

ER90 EVO

The new immediate no contact balancing machine without need of check-spin.
The new ER90 EVO automatically detects wheel data simply pressing one single touchbutton and after a few seconds gives a clear and accurate indication of exact position to place counterweights (clip-on and/or stick-on weights.


Features

  • One Plane Balancing (OPB)
  • AutoAdaptive™ Mode
  • Wheel Structure Analysis
  • Ergonomic Design
  • 3D Laser Scan
  • Side Laser
  • Touch Screen
  • Automatic Positioning System
  • Average 6-second cycle time includes automatic RFV* and wheel scanning performed during the balance cycle.
  • Dynamic AutoAdaptive OPB balancing automatically shifts to a single weight balance on over 70% of today’s wheels; gaining a 33%-time savings on every balance.
  • 220V, 1ph. +AIR
  • Radial Force Vectoring
CEMB’s AutoAdaptive Mode software measures the wheel’s weight and dimensions and then recalculates the tolerance value so as to cancel any vibration perceived on the steering wheel, ensuring the greatest possible driving comfort. CEMB’s OPB (One Plane Balancing) program, 3D Laser Scan and HubMatch, clock the RFV highpoint of the assembly to the vehicle hub before mounting it at the 12 o’clock position. All these features guarantee significant time savings during the balancing process. Also included is a TDC Laser (Top Dead Center) for steel rims.

TECHNICAL SPECIFICATIONS


Power Supply 220V, 1ph, Air
Wheel Clamping Type Pneumatic
Shipping Weight: 485 lbs. (220 kg)
Dimensions:



Max. Rim Diameter 30" (765 mm)
Max. Rim Width 20" (510 mm)
Max. Tire Diameter: 40" (1016 mm)
Max. Wheel Weight: 165 lbs. (75 kg)

DOWNLOAD DOCUMENTS


ER90 EVO Flyer - PDF
